T2430IB
T2430IB
| 辰宇编号TXCM No. | 型号 Type | 行程 Stroke | A | B | 螺纹规格 Thread | 参考编号 Ref.No. | |
| C | D | ||||||
| T1016AA | 10/16 | 57 | 15 | 120.7 | M22*1.5 | M16*1.5 | 925 486 303 0 |
| T1216AA | 12/16 | 57 | 15 | 120.7 | M22*1.5 / VOSS232 | M16*1.5 | 925 486 105 0 |
| T1224A | 12/24 | 57 | 15 | 120.7 | M22*1.5 / VOSS230 | M16*1.5 | 925 466 010 0 |
| T1416A | 14/16 | 57 | 15 | 120.7 | M16*1.5 | M16*1.5 | 925 426 200 0 |
| T1424A | 14/24 | 57 | 15 | 120.7 | M22*1.5 | M16*1.5 | 925 488 020 0 |
| T1616A | 16/16 | 64 | 15 | 120.7 | M16*1.5 | M16*1.5 | 925 464 452 0 |
| T1624G | 16/24 | 57 | 15 | 120.7 | M22*1.5 | M16*1.5 | 925 484 020 0 |
| T2024G | 20/24 | 64 | 15 | 120.7 | M22*1.5 | M16*1.5 | 925 480 010 0 |
| T2224AA | 22/24 | 64 | 15 | 120.7 | M16*1.5 | M16*1.5 | 925 467 016 0 |
| T2416B | 24/16 | 64/45 | 15 | 120.7 | M16*1.5 | M16*1.5 | 925 481 230 0 |
| T2424NK | 24/24 | 64 | 15 | 120.7 | M16*1.5 | M16*1.5 | 925 481 004 0 |
| T2430DB | 24/30 | 64 | 15 | 120.7 | M16*1.5 | M16*1.5 | 925 481 312 0 |
| T3030D | 30/30 | 64 | 15 | 120.7 | M22*1.5 | M16*1.5 | 925 492 102 0 |
